nuc.setupRchExp

nucleardatapy.nuc.setup_rch_exp.rch_exp_tables()

Return a list of the tables available in this toolkit for the charge radiuus and print them all on the prompt. These tables are the following ones: ‘2013-Angeli’.

Returns:

The list of tables.

Return type:

list[str].

class nucleardatapy.nuc.setup_rch_exp.setupRchExp(table='2013-Angeli')

Instantiate the object with charge radii choosen from a table.

This choice is defined in the variable table.

The tables can chosen among the following ones: ‘2013-Angeli’.

Parameters:

table (str, optional.) – Fix the name of table. Default value: ‘2013-Angeli’.

Attributes:

Parameters:

• model (str, optional)

• between (The model to consider. Choose)

R_unit

Attribute radius unit.

isotopes(Zref=50)

This method provide a list if radii for an isotopic chain defined by Zref.

label

Attribute providing the label the data is references for figures.

note

Attribute providing additional notes about the data.

nucA

Attribute A (mass of the nucleus).

nucN

Attribute N (number of neutrons of the nucleus).

nucRch

Attribue R_ch (charge radius) in fm.

nucRch_err

Attribue uncertainty in R_ch (charge radius) in fm.

nucSymb

Attribute symb (symbol) of the element, e.g., Fe.

nucZ

Attribute Z (charge of the nucleus).

print_outputs()

Method which print outputs on terminal’s screen.

ref

Attribute providing the full reference to the paper to be citted.

class nucleardatapy.nuc.setup_rch_exp.setupRchExpIsotopes(rch, Zref=50)

Instantiate the object with charge radii choosen from a table.

This method provide a list if radii for an isotopic chain defined by Zref.

Parameters:

table (str, optional.) – Fix the name of table. Default value: ‘2013-Angeli’.

Attributes:

Parameters:

• model (str, optional)

• between (The model to consider. Choose)

Here are a set of figures which are produced with the Python sample: /nucleardatapy_sample/nuc_setupRchExp_plot.py

Charge radii for Zn, Sn, and Pb isotopes and for the models available in the nuda toolkit.
